ELM327 Bluetooth V2.1 for Android Torque OBD 2 Interface OBD2 Scanner Super MINI ELM 327 Support OBDII Protocols code reader

100 % of buyers enjoyed this product!
Availability: in stock
Color: ELM327 Bluetooth HHOBD Bluetooth Old Bluetooth Vgate Elm327 With switch BT Mini OBDII
Price:  US $3.95
Sale Price:  US $2.92
from AliExpress
45 days Money back 45 days Money back Returns accepted if product not as described, buyer pays return shipping; or keep the product & agree refund with seller.
On-time Delivery On-time Delivery
Guarantees: On-time Delivery 60 days

Note :this link is V2.1

if you want the V1.5 ,pls click here .

V1.5 Link

Super MINI ELM327 Bluetooth V2.1 for Android Torque OBD 2 Interface OBD2 Scanner ELM 327 Support OBDII Protocols code reader

Bluetooth version —–supports Android phone/PC—-connect via bluetooth

It CAN NOT work on IOS, if you need an item which work on IOS, pls buy our WIFI ELM327.

Highlights:

The newly developed wireless scan tool.

It supports almost OBD-II protocols.

It is the latest version 2.1

Bluetooth connection, no Batteries, Cables, or Switches.

Wireless (Bluetooth) 5~ 10 meters

Retrieve Fault Codes (DTCs) and clear Check Engine lights.

Can also be used with a PC with a Bluetooth Card.

Functions:
Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database).
Display current sensor data, including:
1.Engine RPM
2.Calculated Load Value
3.Coolant Temperature
4.Fuel System Status
5.Vehicle SpeedV2.1
6.Short Term Fuel Trim
7.Long Term Fuel Trim
8.Intake Manifold Pressure
9.Timing Advance
10.Intake Air Temperature
11.Air Flow Rate
12.Absolute Throttle Position
13.Oxygen sensor voltages/associated short term fuel trims
14.Fuel System status
15.Fuel Pressure
Features:

Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database).

Clear trouble codes and turn off the MIL (“Check Engine” light)

Set the maximum number of responses to obtain

Remove spaces from ECU responses (to speed data transmission)

Store a unique identifier in EEPROM

Set the CAN mask and filter with one command

Easily switch between variable and fixed CAN message lengths

Send CAN remote frames (RTRs)

Multi-Protocol Support:

1. ISO9141-2(5 baud init, 10.4Kbaud)

2. ISO14230-4 KWP (5 baud init, 10.4 Kbaud)

3. ISO14230-4 KWP (fast init, 10.4 Kbaud)

4. ISO15765-4 CAN (11bit ID, 500 Kbaud)

5. ISO15765-4 CAN (29bit ID, 500 Kbaud)

6. ISO15765-4 CAN (11bit ID, 250 Kbaud)

7. ISO15765-4 CAN (29bit ID, 250 Kbaud)

A.SAE J1939 CAN (29bit ID, 250*Kbaud)

B.USER1 CAN (11*bit ID, 125*Kbaud)

C.USER2 CAN (11*bit ID, 50*kbaud)

*default settings (user adjustable)

Vehicle Coverage:

Works on most of OBD2 Vehicles (1996 onwards in USA) and EOBD vehicles .

But can’t support all OBDII cars.

If you mind this,please do not place order.Thanks.

For Alfa Romeo/ For Ad/ For Bentley/ For BMVV/ For C-adillac/ For C-hevrolet/ For Chrysl/For C-itroen/ For Daewoo/ For F-iat/ For F-ord/ For G-M/ For Hod/ For H-yundai/For Isuzu/For J-aguar/ For J-eep/ For Kia/ For Lad over/ For L-exus/ For M-azda/ For Mercury/ For Mini/ For N-isan/ For M-itsubishi/ For O-pel/ For P-eugeot/ For Posch/ For Re .nault/ For Ro ver/ For Saab/ For Seat/ For Sk-oda/ For Toyt/ For Vauxhall/ For V-olvo/ For VW

For your information:

For your vehicle to be OBD II compliant it must have a 16-pin DLC (Data Link Connector) under the dash and the Vehicle Emission Control Information Label must state that the vehicle is OBD II compliant

Software Included:

Scantool_net113win (Full Version)

EasyOBDII V2.2 (Free Version)

OBD2Spy (Demo Version)

Scan Master-ELM (Demo Version)

wOBDCRAZY (Demo Version)

This hardware can match much other software still! But most of them are not free!

Works for Windows98/ME/2000/XP/Vista & 7!

This tool does not match abs and airbag system!

How to connect with the Phone and Software?
1.Android phone system requirement: Android 4.0-4.4 or higher
2.Software Installation: After insertion of ELM327 Install APP:Install—Continuous click “Next” continue the next installation—Click “Done” Install software
3.Connect Bluetooth:
1)Turn on the Bluetooth switch
2)Find “OBDII” and connect it,the password is: 1234 or 0000
3)Enter the Torque,and set the connection way:Bluetooth,then Choose Bluetooth Device: OBDII


Connection Failure selfcheck on phone:
It is based on bluetooth 2.0,can’t support IOS (bluetooth 4.0).Viecar 4.0 supports Android and IOS.
Please use Android System V4.0 to latest version, and so on.
1.Car is not supported.
2.Engine is not ignited.
3.You need confirm the connection way as below.
Click Menu button setting bluetooth Connection:
Exit Torque,and re-run the software.Successful connection.

Specifications:
Type: code readers & scan tools
Output protocol: bluetooth
Material : plastic
Voltage: 12V
Current: 45mA
Wave frequency: 38400Hz
Applicable scope: 5-10m/ 16.4-32.8ft
Item size: 4.7 * 2.3 * 3.1cm/ 1.8 * 0.9 * 1.2in
Item weight: 21g/ 0.7oz
Total weight: 34g/ 1.2oz

Packing List

A.1*EOBD / OBD2 Bluetooth Diagnostic Interface

B.1*CD.

1.Please Pay Attention About Shipping:

Choose shipping by “China Post Oridinary Small Packet Plus”,No track information (Can’t Monitor) after dispatch from China.

If you don’t receive the goods in 60 days. Please contact us. We will extend the delivery date.

Or you can pay extra money to choose China Post Air Mail with detail track information.

2.Warm Tips:

If the CD is broken or can’t readable, please contact with us to get software download link.

If any questions, please feel free to contact with the seller, please never open a dispute before contact with the seller.

Let’s keep good business relationship. Thanks!!

*This one can’t support Diesel vechicles.

*Can do most of OBDII gasoline cars,but can’t support all OBDII cars

ELM327 can do MOST of the OBDII vehicles, but it CAN NOT do all models.

we also have ELM327 V1.5 firmware Super Mini ELM327 V1.5 Bluetooth



R***r
Verified buyer

всё целенькое. я не селён в электронике , но вроде б всё отлично работает. установил приложение - связь есть через блютуз. некоторые ошибки говорят можно убрать

S***v
Verified buyer

Excellent product, fast delivery! I recommend this dealer!

D***n
Verified buyer

К сожалению посылка до меня не дошло. Деньги вернули.

G***a
Verified buyer

Заказ пришëл быстро , всë работает

S***h
Verified buyer

все хорошо, со своими задачами справляется

L***v
Verified buyer

Спасибо

Customer
Verified buyer

Спасибо, всё работает. Диск с программой на компьютер и на телефон устанавливается без всяких проблем. (Спасибо).

V***n
Verified buyer

Быстрая доставка! В комплекте диск с ПО!

G***s
Verified buyer

very satisfied

Customer
Verified buyer

fonctionne très bien avec logiciels fournis

R***v
Verified buyer

Быстро пришло. Всё работает.

Q***k
Verified buyer

Nog niet getest maar ziet er goed uit

D***v
Verified buyer

Доставка очень долгая, да ещё после проверки оказался не рабочий

D***V
Verified buyer

Доставили очень быстро. Ещё не испытывал .

V***s
Verified buyer

работает с лифан х60,всё Хорошо

G***o
Verified buyer

As always price/quality norms
